Boat Storage Garage, 050G-0027
Boat Storage Garage, 050G-0027

Click image above to view larger

Views may vary slightly from working drawings. Refer to floor plan for actual layout.

Design 050G-0027

Buy this House Plan Now!

Plan Details

Heated Sq. Ft.
  Total  0 sq. ft.

Unheated Sq. Ft.
  Garage  946 sq. ft.
  Loft  562 sq. ft.

Dimensions
  Width  27 ft. 0 in.
  Depth  36 ft. 0 in.
  Approx. Height  23 ft. 10 in.

Ceiling Heights
  First Floor  9 ft. 0 in.
  Second Floor  7 ft. 0 in.

Roof Pitch
  12/12 Main

Roof Framing
  Stick

Exterior Wall
  2x4

Foundation
  Slab

Plan Features

Garage
  Apartment Access - Interior Stairs

Plan Description

Looking for a garage that can do it all? This 2-car garage plan with loft might be the perfect solution to your needs! Two overhead doors open to 946 square feet of usable space on the main level. With the double bay you can easily park two automobiles. The bay on the left is extra deep, perfect for boat storage or parking an oversized vehicle. On the left, a workshop is situated at the rear providing a place to store tools, work on home projects and tinker. Interior stairs lead the way to the upper level loft where you'll find 562 square feet of storage space. You'll appreciate the dormer windows filling the loft with natural light. Just right for families with multiple cars, those who need to accommodate basement or attic overflow, woodworkers and boating enthusiasts, this 2-car garage workshop with boat storage is sure to satisfy your needs.
